PTZ Camera

Pan & Tilt： Pan（0.1°～200°/s），Tilt（0.1°～180°/s）
Rotation： Pan continuously 360°, tilt 0～90° with auto-flip
Preset ：128 preset
Auto-flip：Tilt down 90°, with auto-flip 180°
Patrol：up to 16 patrol
HomePosition：Preset/patrol can be set
Proportional Zoom：Rotation speed can be adjusted automatically according to zoom multiples

CAM SPEC
Chispset：1/2.7",5.0 megapixel, progressive scan, CMOS
Effective Pixels：5MP(2880*1620)@30fps
OPTICS Zoom：Optical 22X, f =5.2mm ~ 114.4 mm
Digital Zoom：Digital:16X
Angle：Appr. 71.7°(Wide) to 2.4°(Tele);(V) 43.4°(Wide) to 1.3°(Tele);
Iris：Auto/Manual,F1.5(W)~F3.4(T)
Min. Illumination：0.002lux (F1.5, AGC ON，colour);0.001lux (F1.5, AGC ON，B/W)
Shutter Time ：Auto/Manual; shutter time: 1 ~ 1/100000 s
IR Range：UP to 150m (492ft)
Noise reduction：2D/3D DNR
Wide dynamic：120dB

VIDEO
Video Compression：Ultra 265,H.265, H.264, MJPEG
H.264 code profile：Baseline profile, Main Profile, High Profile
HLC ：Supported
BLC： Supported
EIS：Supported
Privacy Mask：Up to 8 areas
ROI：Up to 8 areas
Motion Detection：Up to 4 areas

SMART
Behavior Detection：Intrusion, cross line, motion detection, auto tracking
Intrusion： Enter and loiter in a pre-defined virtual region
cross line：Cross a pre-defined virtual line
motion detection：Moving within a pre-defined virtual region
Recognition：Audio detection
General Function：Watermark, IP Address Filtering, Tampering Alarm, Alarm input, Alarm output, Access Policy, ARP Protection, RTSP Authentication, User Authentication

Storage：
Edge Storage：Micro SD, up to 256 GB
Network Storage：ANR

Network：
Protocols：IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP,TLS,SSL

Compatible Integration：ONVIF(Profile S, Profile G, Profile T), API
Network：1 RJ45 10M/100M Base-TX Ethernet

General
Power consumption：9W/25W(IR_LED ON)
Power supply：DC 12V/3A
POE：IEEE802.3at 30W
Temperature：-40℃～+60℃
Installation：Wall /Corner/Pole/Pendant installation
Net weight：5kg
Size ：Product size 350×229mm， Packing size  235*235*460mm
Protection Level: IP66 standard (outdoor dome)
TVS lightning protection, surge protection and voltage transient protection
